Banks Power 2001-2007 LB7/LLY/LBZ & 2011-2019 LML/L5P Duramax Oil Cooler Upgrade Kit

(0) Reviews: Write first review
13252
Cools 31% or better
More cooling plates for better heat rejection
Increased cooling stack surface area
Pre-installed 1/8-inch NPT sensor port for temp or pressure
Includes all hardware
Includes Baldwin B40150 oil filter
Pricing: $610.00

Qty:
Free Shipping - Ground

Description

ENHANCED COOLING FOR EXTENDED TOWING

At the factory-rated 450 horsepower output, the upgraded 19-plate cooler rejects heat 22% better compared to earlier 2017-2019 OE 14-plate oil coolers.
Tuned to 600 horsepower with a higher rpm speed and load, the difference between the two coolers is even larger, with 31% greater heat rejection.
2017-19 vs 20-23 Oil Cooler Heat Rejection
Heat rejection gains are even more impressive on older Duramax engines, which use 10 or 11-plate factory coolers from 01-07 or 11-16 models.
These additional cooling plates and improved oil flow increases the available surface area utilized for heat transfer, shedding more BTUs of heat while maintaining proper oil pressure.
Oil cooler heat rejection chart for previous Duramax generations
Banks chose the Baldwin B40150 oil filter for its superior filtration properties and pressure retention with an Anti-Drainback and 25 PSID Bypass Valve.
Exceeds OEM filtration specs:
99.8% efficiency @ 30 microns
99.1% efficiency @ 25 microns
94.2% efficiency @ 20 microns
Fits all 2001-2007 and 2011-2019 Duramax engines*
Hardware, gaskets, and a Baldwin B40150 oil filter are included as well as a pre-installed 1/8” NPT port for oil temperature/pressure sensors.
Banks chooses with Baldwin Filters for superior filtration
*Due to Enhanced EGR cooling, Kit does not fit late 2007.5-10 LMM Duramax Engines
