HSP Diesel Deluxe No Bridge/Cold Side Bundle Kit For 2015-2016 LML Duramax - HSP-D-594-3-HSP

HSP Deluxe No Bridge / Cold Side Bundle Kit for 2015-2016 Chevrolet / GMC

The 594-3-HSP is best known as the Deluxe Max Air Flow Bundle for the 2015-2016 LML Duramax-equipped Chevrolet and GMC trucks.

This bundle kit is the ultimate solution for increasing and maximizing performance while keeping your factory emissions equipment intact.

What Is the Deluxe Max Air Flow Bundle for the LML?

This is a comprehensive kit for those who want everything in one package. Whether youre using the factory turbo/injection system or drop-in aftermarket options, this kit optimizes your setup.

Cold Air Intake

HSP Diesel upgraded the intake tube to a 4.5" design to draw in maximum airflow. Combined with a premium filter and a heat-shield box, it avoids hot engine-bay air. Dyno testing showed average gains of 20 HP and 58 lb-ft of torque.

Upper Coolant Tube

Replacing the stock rubber coolant tube with a metal version adds reliability and a custom aesthetic. Its available in multiple powder coat options to match your build.

Factory Replacement Coolant Tank

Made from CNC bent and cut aluminum, the replacement tank uses factory provisions and sensor placements, eliminating discoloration and leaks while offering a drop-in fit.

Whats Included in the HSP Deluxe Max Air Flow Bundle?

• 1x LML Hotside Tube (HSP-IN-218)
• 1x 4.5" Cold Air Intake Tube (HSP-IN-150-16)
• 1x Heatshield Box Lid (HSP-IN-746)
• 1x 4.5" Hole Heatshield Box (HSP-IN-749)
• 1x Factory Replacement Tank (HSP-IN-708-16)
• 1x Radiator Hose Tube w/Logo (HSP-IN-239-2)
• 1x 4.5" Filter (RFB-413-RFAB)
• 1x Radiator Cap (RFB-806-RFAB)
• 4x 1/8" Aluminum Rivet (RFB-098-RFAB)
• 3x 10-32 x 3/8" Button Head Screws (RFB-099-RFAB)
• 16x Trim Lock (RFB-411-RFAB)
• 1x LB7-LML Heatshield Box Lid Backer Plate (RFB-746-BP-RFAB)
• 4x M4x.7x10mm Bolt (RFB-901-RFAB)
• 1x 4" T-Bolt Clamp (RFB-424-RFAB)
• 1x 4.5" T-Bolt Clamp (RFB-435-RFAB)
• 1x 4.5" - 4" Straight Boot (RFB-495-RFAB)
• 1x 2.25" T-Bolt Clamp (RFB-420-RFAB)
• 3x 3" T-Bolt Clamp (RFB-422-RFAB)
• 1x 3"x4" Straight Boot (RFB-430-RFAB)
• 1x 2.25" to 3" Reducer Boot(RFB-441-RFAB)
• 14x 1/2" Heater Hose (RFB-400-RFAB)
• 3x 1/2" Worm Gear Clamp (RFB-405-RFAB)
• 1x 1" Worm Gear Clamp (RFB-406-RFAB)
• 1x Low Coolant Sensor LML (RFB-460-RFAB)
• 1x 3/8" Coolant Plug - Aluminum (RFB-808-RFAB)
• 4x 1 3/4" Worm Gear Clamp (RFB-408-RFAB)
• 1x 1.75" 90° Boot - Rubber (RFB-433-RFAB)
• 1x 1.75"x3" Straight Boot - Rubber (RFB-437-RFAB)

Compatibility

This bundle fits:

• LML: 2015-2016
• VIN Code 8

The engine code is found in the 8th character of your VIN, and the 10th character indicates the model year. This kit is specific to 2015-2016 due to engine bay design changes.

Overview

• Increased performance
• Maximizes factory parts and emissions system
• High-flowing cold air intake
• 3" Diameter hot side tube
• High-strength five-layer silicone boots
• Powder coat options for a clean look
• Replaces prone-to-failure factory parts
