HSP Diesel HSP Deluxe No Bridge/ With Cold Side Bundle Kit For 2004.5-2005 LLY Duramax-RAW - D-294-HSP-RAW

HSP Deluxe No Bridge / Cold Side Bundle Kit for 2004.5-2005 Chevrolet / GMC

Part Number: 294-HSP

The 294-HSP is the Max Air Flow Bundle for the 2004.5 and 2005 LLY Duramax Chevrolet and GMC trucks. This bundle features everything you need from the HSP Diesel lineup to unlock more power and maximum performance—while keeping your factory emissions equipment intact.

What Is the Max Air Flow Bundle for the LLY?

This is a complete kit built to take your LLY Duramax to the next level in both performance and appearance. It includes every HSP Diesel component designed for this engine to optimize airflow and reliability using drop-in, emissions-friendly parts.

Billet Forward Facing Thermostat Housing

Solves the bottleneck in the factory coolant system. The stock crossover covers the drivers side valve cover—this billet piece eliminates that, improves cooling efficiency, and frees up space in the engine bay.

Hot Side Intercooler Tube

The factory tube often fails due to rubbing against the power steering line and weak boot retention. HSPs upgraded 3" mandrel-bent pipe fixes both issues with better routing and improved airflow, reducing boost leaks and increasing performance.

Replacement Coolant Tank

The factory plastic tank is prone to cracking. HSPs all-metal, welded coolant tank fits in the OEM location and includes all factory provisions and fittings, including the low coolant sensor.

Cold Air Intake

Built with 4.5" mandrel-bent tubing and a heat shield box, this intake delivers cool, dense air while blocking heat soak. On average, it provides gains of 20 HP and 58 lb-ft of torque. Its designed not to pull hot air from the headlight bezel or fender port.

VGT Intake Mouthpiece

The stock mouthpiece is restrictive. HSPs design allows all incoming air to reach the turbo more efficiently, improving spool-up and overall response.

Cold Side Intercooler Tube

Increased to a 3" diameter to match the hot side and maintain maximum flow throughout the charge system, all while utilizing the factory bridge for a seamless install.

Whats Included:

• 1x Hotside Tube (HSP-IN-207)
• 1x Factory-Style Coldside Tube (HSP-IN-213)
• 1x 4.5" Cold Air Intake Tube (HSP-IN-150-1)
• 1x 4.5" Hole Heatshield Box (HSP-IN-748)
• 1x Heatshield Box Lid (HSP-IN-746)
• 1x Fabricated Turbo Inlet (HSP-IN-216-1)
• 1x Factory Replacement Coolant Tank (HSP-IN-709)
• 1x Billet Thermostat Housing Lower (HSP-IN-715)
• 1x Billet Thermostat Housing Upper (HSP-IN-716)
• 1x Radiator Hose Tube w/ Logo (HSP-IN-229)
• 1x 4.5" Filter (RFB-413-RFAB)
• 1x Radiator Cap (RFB-806-RFAB)
• 1x Thermostat Housing O-Ring (RFB-719-RFAB)
• 4x M8x1.25-25mm Socket Cap Bolt (RFB-909-RFAB)
• 4x M6x1.0-18mm Socket Cap Bolt (RFB-913-RFAB)
• 4x 1/8" Aluminum Rivet (RFB-098-RFAB)
• 3x 10-32 x 3/8" Button Head Screws (RFB-099-RFAB)
• 16x Trim Lock (RFB-411-RFAB)
• 1x Heatshield Box Lid Backer Plate (RFB-746-BP-RFAB)
• 2x M4x.7x10mm Bolt (RFB-901-RFAB)
• 1x 4" T-Bolt Clamp (RFB-424-RFAB)
• 1x 4.5" T-Bolt Clamp (RFB-435-RFAB)
• 1x 4.5" - 4" Straight Boot (RFB-495-RFAB)
• 1x 2.25" T-Bolt Clamp (RFB-420-RFAB)
• 3x 3" T-Bolt Clamp (RFB-422-RFAB)
• 1x 3"x4" Straight Boot (RFB-430-RFAB)
• 1x 2.25" to 3" Reducer Boot (RFB-441-RFAB)
• 1x Turbo Inlet O-Ring (RFB-628-RFAB)
• 18x 3/8" Heater Hose (RFB-395-RFAB)
• 2x 1/2" Worm Gear Clamp (RFB-405-RFAB)
• 4x 1 3/4" Worm Gear Clamp (RFB-408-RFAB)
• 1x 1.75" 90° Boot - Rubber (RFB-433-RFAB)
• 1x 1.75"x3" Straight Boot - Rubber (RFB-437-RFAB)
• 1x Metric Bonded Seal 14mm (RFB-455-RFAB)
• 1x M14x1.5 to 3/8" Hose Barb (RFB-692-RFAB)
• 1x M14x1.5 Metric Port Plug (RFB-969-RFAB)
• 14x 1/2" Heater Hose (RFB-400-RFAB)
• 2x 1/2" Worm Gear Clamp (RFB-405-RFAB)
• 1x 1" Worm Gear Clamp (RFB-406-RFAB)
• 1x Low Coolant Sensor (RFB-459-RFAB)
• 3x M6x1.0x35mm Flange Bolts (RFB-914-RFAB)
• 6x M6 Fender Washers (RFB-915-RFAB)
• 3x M6 Nylon Lock Nut (RFB-916-RFAB)
• 1x 2.25" T-Bolt Clamp (RFB-420-RFAB)
• 1x 3" T-Bolt Clamp (RFB-422-RFAB)
• 1x 2.25" to 3" Reducer Boot (RFB-441-RFAB)

Vehicle Fitment:

LLY Duramax: 2004.5-2005 (8th digit of VIN = 2)

How to Check: The 8th character of the VIN indicates engine code. The 10th character denotes the model year.

Key Benefits:

• Complete performance kit in one bundle
• Fixes common OEM issues
• Powder coat finish options available
• Maintains factory emissions components
• Dyno-proven power increases
• Bundle pricing saves money over individual parts

Our Warranty

HSP “No BS— Limited Lifetime Warranty
We believe in our products and stand behind them. The “No BS” Warranty ensures youre covered. For full terms and claim instructions, click here.
